Concrete batching plant is characterized by high productivity to produce various kinds of concrete, such as plastic concrete, thick concrete and so on. Concrete batching plants are widely used in the large and medium-sized construction site, road and bridge engineering projects as well as concrete pre-production firms. As a concrete batch plant manufacturer, our company has batching plants for sale with competitive price and good performance.

Our company is one of professional batching plant manufacturers. With many years’ experience, we produce and supply various types of concrete batch plant, such as ready mix concrete batching plant,central mix concrete plant, mobile concrete batching plant and so on. Because of special concrete plant design, the concrete mixing equipment accepts a good reputation and is sold very well all over the world.

concrete batching plants

Components of a concrete batch plant:

(1)Aggregate Batching Machine
The aggregate batching system of ready mix concrete machine include aggregate supply system, weighing system and electrical control system. The feeding device is driven by belt.The batching system is controlled by sensor.

aggregate batching machines
(2)Mixing System
Concrete batching plants usually adopt JS series twin shaft concrete mixer as the main mixer. Twin shaft concrete mixer belongs to  forced concrete mixer and has stronger mixing effect and higher mixing efficiency than self-falling concrete mixer. It can be used to mix hard-dry concrete and light aggregate concrete.

JS twin shaft concrete mixer
(3)Cement Silo
As a professional cement silo manufacturer, ChangLi provides bolted type and welded type storage silo in various capacities and dimensions. Bolted cement silo with special design can minimize the transport cost.

cement silo
(4)Electrical Weighing System
The electrical control system of concrete batch plant can control two sets of separate mixer, cement weighing, water weighing, cement weighing and a series of aggregate batching system. The aggregate batching system can automatic control the batching process, connected to high reliable PLC and industry computer.

weighing system
(5) Control System
The PLC programmable controller can control the production process with high reliability and stability. It can control the unloading ingredients, mixing and automatic control of the whole process of the concrete. Moreover, It also can dynamic display the process of weighing and discharging.

control system
(6)Screw Conveyor
LSY screw conveyor is full with a screw inside, and the screw can continually convey materiel.The equipment adopts originated patent feed port, it is easy to install.

screw conveyor

Specifications of popular models:

Projector HZS180 HZS120 HZS90 HZS60 HZS35 HZS25
Rated production 180m³/h 120 m³/h 90 m³/h 60 m³/h 35 m³/h 25 m³/h
Mixer model JS3000 JS2000 JS1500 JS1000 JS750 JS500
Aggregate number 4 4 4 4 3 3
Max aggregate size 80/60mm 80/60mm 80/60mm 80/60mm 80/60mm 80/60mm
Aggregate weighing range 0-3000   kg x4 0-1250 kgx4 0-1000 kg x4 0-2500 kg 0-1800 kg 0-1200 kg
Aggregate weighing accuracy ±2% ±2% ±2% ±2% ±2% ±2%
Cement weighing range 0-1500kg 0-1200kg 0-900kg 0-600kg 0-450kg 0-300kg
Cement weighing accuracy ±1% ±1% ±1% ±1% ±1% ±1%
Water weighing range 0-800kg 0-600kg 0-450kg 0-300kg 0-200kg 0-150kg
Water weight accuracy ±1% ±1% ±1% ±1% ±1% ±1%

At present, we have has many different ready mix concrete plants for sale at low price. If you want to reduce the cost to import the concrete ready mix plant from China, please feel free to contact us at any time.
